Mainly used for checking whole structure under cars,
to make sure whether there is illegal modification,
hidden suspicious object and person,recognize bomb or other attachments.
In addition, the system can be used for safety inspection under the chair,bed,
cabinet and higher places,pipeline,shaft of mine, inside tube , camera obscura,
bushes¡etc,where human body inconvenient to get to.
|
|
|
|
|
|
|
| Specification:
|
| ID: MD2008
Features:
- Adopt 1.0mm strip steel for the products, good appearance,light and handy and convenient to operate.
- High capacity Lithium battery for long time use. Higher capacity battery can be ordered according to different requirements.
- Portable design with wheels and handle, much more easier to operate and move.
- Assistant LED lights design for dark conditions, real- time show the result on LCD screen and avoid facula.
- Foldable design, easy to take with and can detect hole depth 1790mm when it is formed a 180 degree angle .
- The two parts of the products can be locked together when fold,stable and can use a belt to carry with. Package with aluminous box, convenient to move and take with
- Far from fire and electric shock , please do not put the machine in wet place or rain,operation and maintenance pls follow the user manual.
| Model:
| 4 inch Color TET LCD
| Resolution:
| 480(W) ×234(H)
| Display area:
| 82.1(W)×62.8(H) mm
| Dot Matrix:
| 0.171(W) ×0.261(H)
|
| Camera
|
|
| Model:
| F2.5 Wide-Angle CCD
| Rotation Angle:
| 130°
| Adjustment:
| Steel wire control by hand Camera
| Pixel:
| NTSC 512(H) 492(V) / PAL 500(H)482(V)
| Resolution:
| 420 TV lines
| Working Voltage:
| DC 12V 90MA
|
| Battery
|
|
| Capacity:
| 220 MAh
| Recharge Mode:
| Battery recharge alone or united
| Recharge Voltage
| 110~240V
| Output Voltage
| 9~12.6V
| Low battery alarm(Option)
| Buzzer alarm when battery voltage lower than 10V
| Working Time
| About 7 hours Continuous
| Working temperature
| 0~60°C
|
| Gross weight
| 3.5KG
| Volume:
| 1023( Open 1790 )× 149×156 mm
| Packing:
| 115×20×22 cm Aluminum box
| | | | | | | | | | | | | | | | | | | | |
Under Vehicle Search Mirror
ID MD2008A
- Introduction
This product is the latest scientific and technological achievements.
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance,
light weight, and high intensity. Product is suitable for police or security services to carry
out the hidden-check, and to operate for a long time.
Check-mirror can be stretched,
which greatly enhanced the applicability in varieties of environments.
If necessary, the rod can be stretched quickly to have a check,
and operator does not bend over.
The mirror is made of non-friable acrylic instead of ordinary glass plated mercury.
The mirror tray is made of the special materials, which are not easy to aging and broken,
and very durable.
Products are equipped with adjustable hand-held rod.
The range of rod length is from 46cm to 88cm.
The unique folding design brings about space-saving and portability.
The product is portable when its rod is folded on the check-mirror.
One person can take it. When not in use, the product can be disassembled and collected in the portable bag.
( There are two kinds of packages: Aluminum box and carton for your choice )
Offer Rhos and CE
|
- Operation guide
- Rod: Extendible T-bar, fixed by spring with two beads, which are made of high-quality metal and many high-strength processing, is light weight, strong and beautiful. The surface of rod is dealt with baked-paint in the dust-free workshop. The painting does not fade after long-term use, and is odor-free and not harmful to humans. The rod is equipped with black foam handle which has a good holding sense and can be operated comfortable for a long time.
- Power: Built-in lithium battery. To charge 1-2 hours supply for 5-6 hours of operation. It is economical, convenient and practical.
- High-intensity shatterproof acrylic mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special material which is not easy to aging and broken, and very durable.
- The product is designed as 180-degree turn around so that it can detect vehicles or goods in detail as possible.
- Light source: There are two kinds of light sources for your choice: fluorescent lamps and LED. Fluorescent light source is natural and soft. LED is durable, high-brightness, waterproof, removable, and acting as a work light. Customers can choose a suitable light source based on their own operation characteristics. Fluorescent can not be used under humid or rainy conditions.
- When the battery runs out and needs to charge (with a standard power adapter in the package), it is necessary to turn ON. When the green light of power adapter is OFF, it indicates that the battery has been fully charged.
- Attention: When batteries need recharging, the line A must be pulled out, and then turn ON B for charging.
- Operation
First, open the aluminum packaging, take out the check-mirror;
then stretch the rod to carry out operations.
If it is not need, put the rod away into the box.
- Applications
This check-mirror is an ideal tool, which is applicable to check cars,
machinery, warehouses, schools, factories and others difficult to see directly.
It can be used for airport security, parking inspection, the military regional inspection,
and personal checks, such as private cars. We have supplied some corresponding products
for regional Games, important meetings, local police, top hotels and large-scale factories.
- Other parameters
Mirror size: A 30 cm × 30 cm
Product Weight: 2.5kg
Length: 46cm-88cm
Box size: 48×35×16cm
|
Package: 6 PCs per carton
carton size: 59×53×78 cm
Gross weight: 40KGS
|
- Statements
- This manual has been revised carefully to pursue the accuracy and perfect content,
but it is not guarantee to have no omissions or errors.
- The company preserves rights to modify the hardware and software products not to inform users.
- The company keeps the rights of the final interpretation of the manual.
|
|
- Introduction
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance, light weight, and high intensity. Product is suitable for police or security services to carry out the hidden-check, and to operate for a long time. Check-mirror can be stretched, which greatly enhanced the applicability in varieties of environments. If necessary, the rod can be stretched quickly to have a check, and operator does not bend over.
The mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special materials, which are not easy to aging and broken, and very durable. Products are equipped with adjustable hand-held rod. The range of rod length is from 80cm to 137cm. The unique folding design brings about space-saving and portability.
- Operation
- Rod: Extendible Z-bar, fixed by spring with two beads, which are made of high-quality metal and many high-strength processing, is light weight, strong and beautiful. The surface of rod is dealt with baked-paint in the dust-free workshop. The painting does not fade after long-term use, and is odor-free and not harmful to humans. The rod is equipped with black foam handle which has a good holding sense and can be operated comfortable for a long time.
- Mirror: A 30 cm × 30 cm high-intensity shatterproof acrylic mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special material which is not easy to aging and broken, and very durable.
- Light source: There are two kinds of light sources for your choice: fluorescent lamps and LED. Fluorescent light source is natural and soft. LED is durable, high-brightness, waterproof, removable, and acting as a work light. Customers can choose a suitable light source based on their own operation characteristics. Fluorescent can not be used under humid or rainy conditions.
Under Vehicle Search Mirror
ID MD2008B
|
- Applications
This check-mirror is an ideal tool, which is applicable to check cars, machinery, warehouses, schools, factories and others difficult to see directly. It can be used for airport security, parking inspection, the military regional inspection, and personal checks, such as private cars. We have supplied some corresponding products for regional Games, important meetings, local police, top hotels and large-scale factories.
- Statements
- This manual has been revised carefully to pursue the accuracy and perfect content, but it is not guarantee to have no omissions or errors.
- The company preserves rights to modify the hardware and software products not to inform users.
- The company keeps the rights of the final interpretation of the manual.
Mirror size: diameter 30cm
Product Weight: 1. 6kg
Length: 80cm-140 cm
Box Size: 82×22×33cm
|
Package: 10PCs per carton
Carton size: 45×41×89 cm
Gross weight: 30KGS
Offer Rhos and CE
|
| |
|
- Introduction
This product is the latest scientific and technological achievements.
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance,
light weight, and high intensity. Product is suitable for police or security services to carry out the hidden-check,
and to operate for a long time. Check-mirror can be stretched, which greatly enhanced the applicability in varieties of environments.
If necessary, the rod can be stretched quickly to have a check, and operator does not bend over.
The product is designed as 180-degree turn around so that it can detect vehicles or goods in detail as possible.
- Applications
This check-mirror is an ideal tool, which is applicable to check cars, machinery,
warehouses, schools, factories and others difficult to see directly.
It can be used for airport security, parking inspection, the military regional inspection,
and personal checks, such as private cars. We have supplied some corresponding products
for regional Games, important meetings, local police, top hotels and large-scale factories.
Under Vehicle Search Mirror
- Package
Product Weight: 1kg
Mirror size: diameter 15 cm
Packing: 20PCs per carton
Carton size: 65×38×44cm
Gross Weight: 20KGS
- Statements
Offer Rhos and CE
|
ID MD2008C
|
| |
The model designed for a long time check the bottom of the vehicle design, table, chair, the underside of vehicles and other necessary objects leaned english: fixed objects such as temporary in english can be used under the U.S. portable ML subsection. MW for the surprise choice of a search operation.
Cabinets, ceilings as well as other necessary climbing search objects can be removed using the MW or the ML
at the end of round to be checked. According to the actual situation in english, if the light situation, coupled with the torch is equipped with supplementary light source on the target object in order to avoid omission english
Packing list:
Can spin the ball
Wanxiang mobile round
Convex, Washers, Flashlight
|
Package: 4PCs/Carton
Packing size: 86×25×32cm
Gross Weight: 8.5kg
|
| ID MD2008D
Specifications:
- Mirror:
- 33 / 28 centimeters high intensity shatterproof acrylic mirror,
- convex-shaped 2-fold amplification effects
- 1/2 weight of the mirror glass which is of the same size
- With certain toughness, not easy to be broken,
- safe, durable, light and glass the same mirror.
- Ebonite materials surround the botton of the mirror, can effectively prevent the collision cause damage to the mirror.
- Detectable minimum height: 10CM
- Grip:
- T-type retractable rod,
- Turning 170 degrees around the joints designed to maximize the depth to the detection of vehicles and goods,
- Two-ball shrapnel,
- Plastic ring double insurance positioning,
- Use of high-quality aluminum structure and multiple high-intensity processing, light , firm, and beautiful.
- Surface dust-free workshop grilled outdoor paint treatment,
- long-term use of non-bleaching, non-smell, harmless to the human body.
- Cotton with a black foam grip, grip feeling good, fit a long time operation.
- Light source:
- Fluorescent lamp, as well as an optional LED light source.
- Fluorescent light source with a natural, soft characteristics; LED lights have long life,
- high brightness waterproof, removable to serve as work lights and so on.
- Customers can use the characteristics according to their own selection of suitable light source.
- Fluorescent models are adapted to wet and rainy conditions
- Power Supply:
- Internal Lithium-electric charge, 1-2 hours for 5-6 hours operation.
- Economic, convenient and practical.
- With the packaging with standard power adapter.
- Carry:
- folded rod, fixed after a good one person can be put away.
- Can be equipped with easy to carry bag, can be dismantled when not in use and collection.
- Materials are in line with the overall process Rhos standards, suitable export to other countries.
|
Vehicle inspection mirror with a DVR function outer zone SD expansion card slot,
when working, you can also record the whole working process, can also record the
file through the USB interface on the device to save the file to a computer or other
storage media to facilitate a long time to save data.
In addition, the device's display do not only has the general features of the liquid crystal display,
but also a multi-function multimedia player. In your spare time, you can play multimedia files and browse e-albums and book. details please following the use of product operation
|
| DVR vehicle inspection mirror
ID MD2008E
Introduction LCD / DVR
- Function keys
- Basic function and the introduction of Icon
To allow users to quickly master the use of the product,
the product instructions, only highlights the surveillance video recording and video playback capabilities,
other functions, depending on introduction to learning the use of function keys
- A music player: Support MP3/WMA/AMR/ACC/FLAC/AP
- Video display: Support RM/RMVB/3GP/MP4/FLV/AVI/ASF
- Picture browsing Support JPEG format pictures, Full screen display, thumbnail display, slide show.
- E-book: You can read TXT text.
- Audio: microphone recording.
- Shooting
- Video output
- Surveillance video: This function will explain the details on the operating instructions.
- Games and calendar functions
- System Setup Function
- Function with a SD expansion slot
Package: 3PCs per carton
Carton size: 86 × 35 × 28 cm
Gross Weight: 18KG
|
| Specification
- CAMERA£º
Resolution: 1 / 3 inch
Chip: 420 line Sharp CCD
Power Supply: DC12V
Automatic infrared night vision function
- LCD/DVR
Screen size: 4 inches
Resolution: 480 × 320 × RGB
Power supply: Built-in 3.7V rechargeable battery
PACKAGE LIST
One Camera
One Host Box£¨with Aluminum£©
One DVR /LCD
Two Charger £¨13.8V/1000mA¡¢5V/1A£©
BATTERY
- HOST BOX CHARGE
When the screen images distorted or no images and the indicator behind the host box is not extinguished,
you should charge the host box. Using the 13.8V/1000mA charger to change the Host Box, at the process,
at first it is red, when full, it is green
- LCD/DVR CHARGE
When appears the low-voltage logo on the screen or automatic shutdown,
you need to use the 5V/1A of small charger to charge the DVR.
Charging time is normally 4-8 hours, preferably not more than 8 hours,
or DVR's Built-in battery life will be affected. In the process of charging,
DVR the will be a small indicator light is red on the lower right corner of DVR ,
green when it is full.
| |
|
|
|
Visual inspection under the vehicle mirror
Simple operation, press the boot button can be used to examine the car, machine, warehouse,
schools, factories, equipment, or other areas to watch the ideal directly,
it can be used to check mirrors airport security, parking area military private individuals, etc.
Product features
The display USES color pigment 265 million TFT LCD digital. Exclusive exploitation has driven plate,
about five times the image and strong function of electronic variable light etc.
Make your picture more bright colored color more lifelike. SONY, a CCD camera using sensor,
10~16 feet, make you even in infrared night also apply to normal.
Using aircraft type triangular wheels, operation, use lighter more comfortable.
Specifications
Voltage: DC12V
Current: 220mA
3.5inch TFT LCD digital
Resolution: 320 × 240
Analytic: 420 line level
Power supply:
rechargeable lithium
battery protection
SONY CCD camera:
the sensor
Wide-angle lens perspective: 120 °
Infrared distance: 10~16 feet
|
Package: 3PCs/Carton
Packing size: 86×35×27cm
Gross Weight: 23kg
|
|
| ID MD2008G
embed the triangle turn-plate into the red nylon ball.
|
|
| pull the thin aluminum pipe out of the thick one, then circumvolve the thin one to lock the whole telescopic pole.
|
|
| Please connect the mirror and the pole by inserting the thin pole into the joint on the mirror.
|
|
| As shown in Pic6, fix the spare electric torch on the telescopic pole and finish the installation.
|
|
|
Operation
Bottom Explanation of inspection Mirror
- For more convenient to use, please install the triangle turn-plate first when use the inspection mirror.
And the turn-plate can be turned 360°
- You may turn on the spare electric torch either on the top or on the bottom to get a better view when the light is not bright enough.
- If the telescopic pole is not long enough, you may choose any of the four additional lengthen poles, and every one of them has handgrip.
Top Explanation of inspection Mirror
- You don't need to install the triangle turn-plate. And you can adjust the angle of inspection mirror by the revolving button accommodated.
- You may turn on the spare electric torch either on the top or on the bottom to get a better view when the light is not bright enough.
- If the telescopic pole is not long enough, you may choose any of the four additional lengthen poles,
but every one of them has handgrip.
|
|
Model: MD2008H
Intelligent Under vehicle inspection System
Product Introduction£º
MD2008H type under vehicle inspection equipment is a multifunction security new product.
It can show clear images of 4 directions in the same time and expanding our field of vision.
There are two modes at security check: mobile mode & fixed mode.
For checking banned substance on the bottom of vehicle.
It can be also installed in allow vehicles of all kinds of places of inward and outward or access to be seized vehicles, the bottom acquisition vehicle image to determine whether the bottom with bombs, drugs to prohibited item.
This product has the DVR function, very convenient to save the images to SD card to do backup work, let security personnel fast inspection, improve the work efficiency.
The product is suitable for use in the airport, seaport, customs, prison, the military restricted zones and the hotel security for automobile chassis for inspection area. Below is the function of the product introduction and instructions for use. please read carefully, wish you enjoy using it.
Function Introduction£º
- 15inch-LCD panel Introduction
| Display panel
| 15 inch color LCD panel
| Resolution
| 1280x1024
Support multinational language menu
| SD card digital recording
| Recording format
| AVI
| Storage medium
| SD card
| Power
| DC
| 12V
| | | | | |
Installation
- Connecting rod-1
- Connecting rod-2
- U-Iron clip
- leading wire
- camera head-1
- camera head-2
- camera head-3
- camera head-4
- LED light filling
- Bottom plate
- wire connecting head
- Pick up the connecting rod-2, the bottom plate and the screws. Fixed the connecting road-2 on the U-clip of bottom plate, tighten the screw.
- Connect the leading wire to the bottom plate.
- Connect the connecting rod-2 to the connecting rod-1
- fix the leading wire with the Velcro straps
- Finish installation
Camera head
- The instrument has four hd SONY camera , We can watch the pictures from different directions
- This equipment with the filling light source, 12v LED high brightness lights supplement, it will be more clear while in insufficiency light, and fill-in light for the camera. light fitting luminance is accommodation.
|
|
-
Digital recording box
- Control switch
- Camera brightness adjustment
- Video output socket
- Battery power indication
- DVR-up Choose
- DVR-left choose
- DVR-Menu choose
- DVR-down choose
- DVR-right choose
- Camera head connecting
- DVR-Recording/stop/play
- DVR-file display
- DVR-video stop
- DVR-playback
- Charge socket
- Double track headset socket
- SD card socket
- Microphone plug
- Fuse socket
- 4 screens interface
|
|
- Digital recording button operation
| ¡ü
| Menu up choose
|
|
| ¡ý
| Menu Down Choose
| ←
| Menu Left choose
| →
| Menu Right choose
| OK/Menu
| OK/Menu
| Power
| Power indication
| Status
| Working status
| Playback
| Video playback
| Stop
| Stop play
| Preview
| Video preview
| Rec.
| Manual recording & stop
| | | | | | | | | |
- Icon instruction
| SD insert
|
|
Manual video mode
Manual shoot mode
Auto checking mode
Moving checking mode
Date 2010/03/31
| Time 16:29:45
| | | | | |
Data/time setting
- Before using, insert the SD into the VCR. Press 'ok/menu' to the Menu screen, and press '→'to clock icon.
- Choose the 'Set time/Date' and press 'ok' to enter the time/date setting. press 'left' or 'right' icon to choose the setting item. 'up' & 'down' is adjusting the time. after setting , press ok and return back to last menu.
- User can set the data format according to your habit. For example£º YY/MM/DD or DD/MM/YY. ( YY:year MM:month DD:date )
- Master Capture
- press 'ok' enter the menu, choose the
icon. And press 'Master Capture' enter the setting.
- There are 4 chooses, function as following
Photo 1: Master Capture, every operation for shoot 1 picture
Photo 3: Master Capture, every operation for shoot 3 pictures
Movie: Master Capture, every operation for start record & REC file
Movie Clip: Manual recording, every operation for start record and the file is 10sec/chapter
- Auto Capture recording setting
- Press 'OK' enter into the Menu, choose the
 icon. and enter to the 'Auto capture' setting.
Auto Capture: press ok, choose 'on' for start on the Auto capture. choose 'off' to shut up Auto capture.
- Mater Capture: in this mode, there are 4 working status:
Photo 1£ºAuto Capture, every operation for shoot 1 picture
Photo 3: Auto Capture, every operation for shoot 3 picture
Movie 5s: Auto Capture, every operation for start record and the file is 5sec/chapter
Movie 10s: Auto Capture, every operation for start record and the file is 10sec/chapter
- Movie Pre Record£º
Press 'on' is start-up, 'off' is shut down the function of Movie Prerecord.
This function can help to record the two parts of the documents, the first paragraph for the second video recording interval before 2-3 seconds sound.
- File Over Write Setting
Press 'on' is start-up, 'off' is shut down the function of File Over Write .
After starting this function, when the memory space is less than 10 MB, the system will auto-delete the forehand 100MB file for saving new file.
- Motion detect range & sensitivity setting
Press OK to enter the Menu. Choose the
icon, enter the motion detect range & sensitivity setting.
Range,Motion detect range£ºpress direction choose 1/1 (full screen),1/4screen, 1/16 screen is control area.
Timeslot, Time interval: motion detecting scanning time interval. Can choose: 1 Sec/time, 3sec/time, 5sec/time.
Sensitivity, Motion detect sensitive£ºAccording to the direction key choose the sensitivity of Low, Middle or High. The higher the sensitivity, motion detecting triggering possibility is higher.
- Photos quality & standard setting£º
- Press OK enter the menu, choose
icon. Enter the photos quality & standard setting.
- Photo Quality, (Please see below form of resolution details)
- High quality
- Standard quality
- Low quality
- Movie Quality,(Please see below form of resolution details)
QVGA,QVGA---Image resolution
Resolution parameters
| States
| Video
| Image
| CHI
| CHI
| D1&HIGH
| 720×576
| 720×576
| D1&Standard
| 720×576
| 720×576
| D1&Low
| 720×576
| 720×576
| QVGA&HIGH
| 360×288
| 720×576
| QVGA& Standard
| 360×288
| 720×576
| QVGA& Low
| 360×288
| 720×576
| | | | | | | |
- TV Output Standard, TV output format choose according to different countries TV format, UP & down key to choice the PAL or NTSC system, click OK to determine and exit
- Video playback
In standard mode, press the 'playback' enter the video playback mode. according to the date showing, press the "←""→"key to play the needed video. and press "Rec." can restart.
- DVR file more frames preview£º
Video playback mode, press the 'Preview' key, we can see preview the 6 photos. and according to the data showing, press "←""→"key to move the yellow selection box. choose the needed video and click 'OK', then play video.
- DVR file deleting£º
In standard mode, press "Playback" to enter the video play mode, click the file you need to delete, and click the ok .At this time, according to the key tips 'File delete' to choose the operation, press the "OK" button execution.
Format:
format all the files in SD card (this operation executed, SD card will be lost in all the documents, can't restore)
- Computer access to files
Insert the SD card to computer, click "my computer" choose "moving disk". And enter the file which named "CCTV".
Enter this folder, and we see some folders inside.. These folders are named by the date of the generation.
Sample£º10032600. The format is: year, month, date,
Enter the folder; we can see some videos or photos. These videos or photos are named by the time of the generation.
Sample:133105-1.. The format is: hour, minute, second
Users can use the ordinary player to play the video. For images files it's jpg format.
- 15inch display panel characteristics
| fps
| Pal:25f/sec, NTSC:30f/sec
| Resolution
| D1:720X576
QVGA:360X288
| Compressed format
| M-JEPG & Standard JPEG
| Detecting mode
| Auto capture
| Working mode
| Recorder/shoot
| Memory
| SD/SDHC¿¨,≤32GB
| Power
| DC12V (5V-36V customized )
| Working current
| ≤250Ma
| Working temperature
| -10°C~+50°C
| Working humidity
| 20%~85%
| | | | | | | | | | |
- 4-ways of color video processor
- system characteristics£º
(1) Link 1-8 camera video signal, adjustable brightness, contrast and saturation, color and sharpness
(2) high definition
(3) NTSC standard£º720x480¡¢60hz,PAL format£º720x576¡¢50hz
(4) The diversity of the display mode, four frames, the two images, single picture, the paint of paint to be automatic switch display mode
(5) High performance screen freezes function: flashing pictures capture
(6) high-performance graphics electronic amplification function, can choose magnified area
(7) Diverse characters cascade information, a camera in the title, headlines and real-time and alarm date/video lost/motion detecting information.¡£
(8) menu language support in both Chinese and English, can be in four exchange pictures and single picture mode playback¡£
(9) provide several input methodes£º(if need for external alarm output function, need another request to add this function)Alarm input, video lost detects, motion detecting can record article 60 incident reports, built-in buzzer alarm¡£
- Panel key function
Definition: short press buttons don't more than 1 second, long press please more than 1 second¡£
- MENU: long press into the main MENU, exit key, short for enter A or page
- AUTO: long press into single picture switch, short for screen freezes in.
- ZOOM : long press enter magnifier function, first short press for image-2, the second short press for image 1, the third short press for two images, the fourth press is 8 picture.
- VCR: long press into the picture, short press for playback by entering/exit channel model, in the menu key change under the mode of menu for ok button.
- 1/5 key : for the camera first channel and the fifth channel, up & left control function
- 2/6 key : for the second and sixth channel camera channel, up & right control function
- 3/7 key : for the third and seventh channel camera channel, menu mode left key for menu mode for moves left reduce function
- 4/8 key : for the fourth channel and channel 8 camera, menu mode right shift to increase function
- Menu
Step£ºUnder any mode , we long press the MENU button, can enter to the main MENU.
(1) Menu setting method£ºlong press MENU enter the main menu click "¡÷¨Œ"key to chanage the cursor choose the menu item.,press ENTERkey to confirm,click"¡÷¨Œ"for left & right moving,and click""forincrease the reduced parameter
(2) System setting
In MENU mode we click "¡÷¨Œ"to choose the ¡®system setting¡¯ and press ¡®ENTER¡¯ to enter
Setting Option.
×1for data: Year, month, day setting£»
×2for time, Hour, minute, second setting
×3 for NTSC¡¢PAL setting£»
×4 for menu language Chinese / English exchange£»
×5 for factory re-set£ºmove the cursor to ¡®OK¡¯ press "ENTER"and choose "YES" press "ENTER" to confirm,after reset safety it auto return to menu. After long press ¡®MENU¡¯ reset finish.
- Display setting
Press "¡÷¨Œ"to move the course to "dispay setting" and click ¡®ENTER"into display setting
×1 For the camera title switch
×2. For the date switch
×3 For the time switch
×4 For the line coordinate position setting .
×5 For the line coordinate color and the line coordinate switch
- Repeat setting
Under the main menu model
"¡÷¨Œ" key cursor selected "repeat setting" then press "ENTER" key into setting options.
OFF show automatically switch to turn off. automatically switch to time 00-99 seconds then can be changed, ( 4 line splitter default all single screen.)
Automatically switch to turn on,8 line splitter default all single screen will automatically switch to turn off
- Channel setting
When use "¡÷¨Œ" key selected " channel setting" key then press "ENTER" key into setting options
×1 show the title setting mode, press ""key will appear Character box,
According to the change in the box title character
×2 show adjustable brightness, contrast, color, saturation, sharpness
×3 For image setting mode, when setting selected "ON" press
The camera signal will such as a mirror display opposite direction .then the default setting is "off" press "MENU" key to exit.
- Remove setting
Under the main menu mode with "¡÷¨Œ" key select the "Remove Settings" and then press "ENTER" to ENTER setting options
×1, Surveillance time switch Settings, when set choose "ALWAYSON" it will be effect.
×2,Surveillance's sensitivity
×3,Surveillance's area coordinates
- Event setting
Under the main menu mode with "¡÷¨Œ" key select the "Event Settings" and then press "ENTER" to ENTER setting options
×1,external alarm, video lost, motion Surveillance switch Settings.
×2,The delay time of the buzzer alarm
×3,Time to record the delay time.
×4,The discretion of the potential buzzer alarm Settings
- Event report
Under the main menu mode with "¡÷¨Œ" key select the "Event report " and then press "ENTER" to ENTER setting options
1,NO¡¢DD-MM-YY¡¢HH£ºMM£ºSS¡¢CH¡¢EVENT they are showed the number of alarm , date, time, the channel and the type of event.
2, LISTCLEAR For all the records are empty
Note: Take NO set to YES then press ENTER key confirm completely empty. This report total 6 pages, it can record 60 pcs incident reports.
- Four ways color video processor parameters
- Note
(1) Please read the manual carefully before using this system.
(2)Avoid using the device in extremely cold, heat, moist area, it may damage the device.
(3)Please back up the SD card always, and do not forced pull off the SD card when it is on working, because it easy to damage the instrument and the SD card.
(4)Please make sure all accessories connected, and then open the power, and the monitor and DVR will set up after 5 seconds of power on.
(5)Please adjusts light complement such as LED, so that let the image showed as the best effect. Adjustment the brightness, color and contrast to let the display is best.
(6)If you want to view with big screen, please let video output connected to input of large screen display.
(7)Please install fuse (F3A250V) before using it.
(8)after used the machine, please clean up the equipment, wipe off the residue.
- After-sales Service
This product can be replacement within one month from the date of purchase.
if it is belong the products itself problem, we can supply one year warranty period after our company confirmed.
And for improper operation we can provide free repair, but need the purchase paid the repaired material cost.
Please include you original purchase data.
This warranty does not apply to accident, improper use, improper maintenance, disassemble the equipment and the failure caused by misuse of equipment, this is also not suitable for non-authorized personnel have done any maintenance equipment.
- Legal Liability
(1) Law interpretation
The manual interpretation and reproduction rights belong to the Company.
(2) Trademark Right
The vehicle inspection mirror instrument¡¯s model name, logo belong to our company right. Please do not copy it.
(3) Tortious Liability
Without the Company's permission to reproduce or use the equipment and equipment of our company name, logo, belong to the infringement, should bear all the resulting of legal liability.
- Packing list
- 15 inch display
- color video processor
- the connecting rod (2pcs)
- the signal lines
- charger,
- digital video recording box
- bottom camera device,
- product specification
- adjustable wrench
- Technical parameters
- Camera: Sony, pixel CS (dpi);
the type of model: G639 + S3172 +2096;
Type: CCD main board; image sensor: 1/3-SONY COLOR ;
level resolution: 480 (TVL, Minimum illumination 0.1 (Lux), resolution of 480TV Lens CS (mm), SNR> 48 (db), back light compensation :AUTO; Size: 1 / 3 (inch)
- Operating voltage: DC12V (rechargeable)
- Rod Length: 1.3 m
- Camera base device height: 9.5cm
- Operating temperature: -10 °C - +50 °C (°C)
- Net weight: 8.6Kg
- GW: 15.1Kg
- size:
Display: 46.6 × 19 × 38.5cm
Body packing: 74 × 42 × 7cm (Aluminum Packaging)
|
| Compact Pocket Search Mirror and Torch MD2008I
Pocket Under Vehicle Search security Mirror with carry case
Pocket Search Mirrors provide a quick and effective visual search capability for law enforcement
officers and for individuals with personal security concerns.
In addiction, specialized task units often require a similar capability optimized for tactical use.
A compact search mirror that can be carried as an aid to personal security or as an individual issue by operational personnel.
Fitted with a convex glass mirror, telescopic arm and a miniature flashlight. The PMT folds flat for carrying in a jacket/uniform pocket or bag and weighs only 260g(9.2oz)
The pocket mirror can be adjusted for angle and provides a wide field of view.
The unique telescopic handle extends to 460mm(18.1in) and is completely rigid to ensure a stable image.
The integral flashlight can be used with the mirror open or closed.
A tactical version of the pocket search mirror fitted with an acrylic mirror.
|
|
The PMT can be used in operational scenarios (e.g. police SWAT) where unobtrusive close in observation is required by individual officers. During IEDD tasks the
PMT allows a quick confirmatory visual check to be made before positive action is taken against a suspected hazardous device.
The small, lightweight and similar situations where other visual search mirrors would be too large or widely.
Supplied with 2x AAA batteries and a spare lamp in a stowage compartment.
Overall dimensions closed (both versions): 155×90×20mm ( 6.1×3.54×0.079inch ) Weight: 250g ( with battery )
|
|
|
|
|
Components
- Telescopic set
- Torch cap
- Mirror
- Torch body
- Spare bulb
- Bulb
|
HOW TO USE
- The telescopic set was combined by 8 sections aluminum rods which could be extend or fold easily without tools.
- The users could adjust to a idea length for more convenient searching work.
Caution
- Please do not over extend the rods set by force. It may cause the nylon junction parts break.
Battery or Bulb Replacement
- Simply unfold to suitable viewing angle. The torch operates by the Push button. The handle may be extended by pulling outward from the Centre finger recess, located next to the torch on/of button.
The torch May also be used with the mirror folded flat.
To remove the torch batteries and bulb, grip the top cap and unscrew Anti-clockwise. This will be found easier with the handle sections extended.
Caution
- Batteries and bulb will new drop out when the torch is up ended. A spare bulb is supplied, located in the torch lamp head, removing the rubber grommet will allow access.
Maintenance : Install batteries correctly, observing the polarity + - signs to avoid leakage. Always replace sets of batteries at the same time, taking care not to mix old and new batteries from equipment.
Batteries replacement batteries : 2xMN 2400 or similar. Size AAA1.5.
|
|
MD2008J
Introduction
This product is the latest scientific and technological achievements.
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance, light weight, and high intensity.
Product is suitable for police or security services to carry out the hidden-check, and to operate for a long time.
Check-mirror can be stretched, which greatly enhanced the applicability in varieties of environments.
If necessary, the rod can be stretched quickly to have a check, and operator does not bend over.
The mirror is made of non-friable acrylic instead of ordinary glass plated mercury.
The mirror tray is made of the special materials, which are not easy to aging and broken, and very durable.
Products are equipped with adjustable hand-held rod.
The range of rod length is from 46cm to 88cm.
The unique folding design brings about space-saving and portability.
The product is portable when its rod is folded on the check-mirror. One person can take it.
When not in use, the product can be disassembled and collected in the portable bag.
(There are two kinds of packages: Aluminum box and carton for your choice)
Operation guide
Rod: Extendible T-bar, fixed by spring with two beads, which are made of high-quality metal and many high-strength processing, is light weight, strong and beautiful. The surface of rod is dealt with baked-paint in the dust-free workshop. The painting does not fade after long-term use, and is odor-free and not harmful to humans. The rod is equipped with black foam handle which has a good holding sense and can be operated comfortable for a long time.
Power: Built-in lithium battery. To charge 1-2 hours supply for 5-6 hours of operation. It is economical, convenient and practical.
Mirror: A 30 cm ¡Á 30 cm high-intensity shatterproof acrylic mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special material which is not easy to aging and broken, and very durable.
Operation steps
First, open the aluminum packaging, take out the check-mirror; then stretch the rod to carry out operations.
If it is not need, put the rod away into the box
when the battery runs out and needs to charge (with a standard power adapter in the package),
it is necessary to turn ON. When the green light of power adapter is OFF, it indicates that the battery has been fully charged.
|
In a dark place, you can turn on the lamp switch
|
Other parameters
Product Weight: 2.5kg
Total weight: 4.6kg
Length: 50cm-100cm
Packaging: 50cm¡Á35cm¡Á18cm
Statements
- This manual has been revised carefully to pursue the accuracy and perfect content, but it is not guarantee to have no omissions or errors.
- The company preserves rights to modify the hardware and software products not to inform users.
- The company keeps the rights of the final interpretation of the manual.
The materials are in line with Rosh technology standards
| |
Package: 1PC per carton
- Aluminum trunk 48cm × 39cm × 19.5cm
material: fire protection
- Carton size: 50 × 40 × 20cm
- Gross weight: 10KG
|
Pipe Inspection Camera
Special feature: Waterproof / Weatherproof
- pipe inspection equipment
- pipe & wall inspection system
- sewer services inspection
Specification
Camera
| camera size:
| 23mm×120mm Front size:45mm
| Camera case material:
| stainless steel house stainless steel 304
| Camera glass material:
| saphir glass
| sensor size:
| 1/4 inch
| Total Pixels:
| PAL:720×576 NTSC: 720×480
| view angle:
| 120°
| camera light:
| 12PCS white LEDS
Special gold point touch connector
| waterproof:
| IP68
| camerawork current:
| 100MA
| camera power supply:
| DC 12V
LEDS ADJUASTABLE
| Work temperature:
| -10°C-50°C
| | | | | | | | | | | | |
Monitor
| monitor size:
| 7inch TFT color monitor
| monitor Total Pixels:
| 1440×234
| monitor power supply:
| DC 12V
| display language:
| English
up,down left,right adjustable
| Model
| 16:9 4:3
sunshade include
waterproof connector
| Work temperature:
| -10°C-50°C
| | | | | | | | |
DVR
| DVR power supply:
| 12V
| DVR work current:
| 200MA
| storage medium:
| SD card (max 32G)
digital clock and digital calendar
| DVR Total Pixels:
| 720×576 (D1)
picture snap and movie record
| movie format:
| AVI
audio record (yes)
| double earphone output
| | | | | | | | |
Audio input unit
- microphone
- clip type
Cable wheel
- Cable size:320MM(diameter)×110(h)
- Wire material: fiberglass rod
- Fiberglass length:20M( standard)
- Fiberglass diameter:4.8MM
- Fiberglass color:yellow
Battery
| Battery type:
| 12V 4000MAH rechargeable
Li-ion battery(18650)
| Work time:
| 7 hours
| |
Charger
- Input: AC90-260V
- Output: DC 12V 1000MA
- Output cable length:1.5M
- DC plug diameter :2.1MM
SKIDS size
- SKIDS1: ¦µ40MM
- SKIDS2: ¦µ80MM
|
Mainly used for checking whole structure under cars,
to make sure whether there is illegal modification,
hidden suspicious object and person,recognize bomb or other attachments.
In addition, the system can be used for safety inspection under the chair,bed,
cabinet and higher places,pipeline,shaft of mine, inside tube , camera obscura,
bushes¡etc,where human body inconvenient to get to.
|
| |
|
|
|
|
|
|
|
| Specification:
|
| ID: MD2008
Features:
- Adopt 1.0mm strip steel for the products, good appearance,light and handy and convenient to operate.
- High capacity Lithium battery for long time use. Higher capacity battery can be ordered according to different requirements.
- Portable design with wheels and handle, much more easier to operate and move.
- Assistant LED lights design for dark conditions, real- time show the result on LCD screen and avoid facula.
- Foldable design, easy to take with and can detect hole depth 1790mm when it is formed a 180 degree angle .
- The two parts of the products can be locked together when fold,stable and can use a belt to carry with. Package with aluminous box, convenient to move and take with
- Far from fire and electric shock , please do not put the machine in wet place or rain,operation and maintenance pls follow the user manual.
| Model:
| 4 inch Color TET LCD
| Resolution:
| 480(W) ×234(H)
| Display area:
| 82.1(W)×62.8(H) mm
| Dot Matrix:
| 0.171(W) ×0.261(H)
|
| Camera
|
|
| Model:
| F2.5 Wide-Angle CCD
| Rotation Angle:
| 130°
| Adjustment:
| Steel wire control by hand Camera
| Pixel:
| NTSC 512(H) 492(V) / PAL 500(H)482(V)
| Resolution:
| 420 TV lines
| Working Voltage:
| DC 12V 90MA
|
| Battery
|
|
| Capacity:
| 220 MAh
| Recharge Mode:
| Battery recharge alone or united
| Recharge Voltage
| 110~240V
| Output Voltage
| 9~12.6V
| Low battery alarm(Option)
| Buzzer alarm when battery voltage lower than 10V
| Working Time
| About 7 hours Continuous
| Working temperature
| 0~60°C
|
| Gross weight
| 3.5KG
| Volume:
| 1023( Open 1790 )× 149×156 mm
| Packing:
| 115×20×22 cm Aluminum box
| | | | | | | | | | | | | | | | | | | | |
Under Vehicle Search Mirror
ID MD2008A
- Introduction
This product is the latest scientific and technological achievements.
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance,
light weight, and high intensity. Product is suitable for police or security services to carry
out the hidden-check, and to operate for a long time.
Check-mirror can be stretched,
which greatly enhanced the applicability in varieties of environments.
If necessary, the rod can be stretched quickly to have a check,
and operator does not bend over.
The mirror is made of non-friable acrylic instead of ordinary glass plated mercury.
The mirror tray is made of the special materials, which are not easy to aging and broken,
and very durable.
Products are equipped with adjustable hand-held rod.
The range of rod length is from 46cm to 88cm.
The unique folding design brings about space-saving and portability.
The product is portable when its rod is folded on the check-mirror.
One person can take it. When not in use, the product can be disassembled and collected in the portable bag.
( There are two kinds of packages: Aluminum box and carton for your choice )
Offer Rhos and CE
|
- Operation guide
- Rod: Extendible T-bar, fixed by spring with two beads, which are made of high-quality metal and many high-strength processing, is light weight, strong and beautiful. The surface of rod is dealt with baked-paint in the dust-free workshop. The painting does not fade after long-term use, and is odor-free and not harmful to humans. The rod is equipped with black foam handle which has a good holding sense and can be operated comfortable for a long time.
- Power: Built-in lithium battery. To charge 1-2 hours supply for 5-6 hours of operation. It is economical, convenient and practical.
- High-intensity shatterproof acrylic mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special material which is not easy to aging and broken, and very durable.
- The product is designed as 180-degree turn around so that it can detect vehicles or goods in detail as possible.
- Light source: There are two kinds of light sources for your choice: fluorescent lamps and LED. Fluorescent light source is natural and soft. LED is durable, high-brightness, waterproof, removable, and acting as a work light. Customers can choose a suitable light source based on their own operation characteristics. Fluorescent can not be used under humid or rainy conditions.
- When the battery runs out and needs to charge (with a standard power adapter in the package), it is necessary to turn ON. When the green light of power adapter is OFF, it indicates that the battery has been fully charged.
- Attention: When batteries need recharging, the line A must be pulled out, and then turn ON B for charging.
- Operation
First, open the aluminum packaging, take out the check-mirror;
then stretch the rod to carry out operations.
If it is not need, put the rod away into the box.
- Applications
This check-mirror is an ideal tool, which is applicable to check cars,
machinery, warehouses, schools, factories and others difficult to see directly.
It can be used for airport security, parking inspection, the military regional inspection,
and personal checks, such as private cars. We have supplied some corresponding products
for regional Games, important meetings, local police, top hotels and large-scale factories.
- Other parameters
Mirror size: A 30 cm × 30 cm
Product Weight: 2.5kg
Length: 46cm-88cm
Box size: 48×35×16cm
|
Package: 6 PCs per carton
carton size: 59×53×78 cm
Gross weight: 40KGS
|
- Statements
- This manual has been revised carefully to pursue the accuracy and perfect content,
but it is not guarantee to have no omissions or errors.
- The company preserves rights to modify the hardware and software products not to inform users.
- The company keeps the rights of the final interpretation of the manual.
|
|
- Introduction
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance, light weight, and high intensity. Product is suitable for police or security services to carry out the hidden-check, and to operate for a long time. Check-mirror can be stretched, which greatly enhanced the applicability in varieties of environments. If necessary, the rod can be stretched quickly to have a check, and operator does not bend over.
The mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special materials, which are not easy to aging and broken, and very durable. Products are equipped with adjustable hand-held rod. The range of rod length is from 80cm to 137cm. The unique folding design brings about space-saving and portability.
- Operation
- Rod: Extendible Z-bar, fixed by spring with two beads, which are made of high-quality metal and many high-strength processing, is light weight, strong and beautiful. The surface of rod is dealt with baked-paint in the dust-free workshop. The painting does not fade after long-term use, and is odor-free and not harmful to humans. The rod is equipped with black foam handle which has a good holding sense and can be operated comfortable for a long time.
- Mirror: A 30 cm × 30 cm high-intensity shatterproof acrylic mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special material which is not easy to aging and broken, and very durable.
- Light source: There are two kinds of light sources for your choice: fluorescent lamps and LED. Fluorescent light source is natural and soft. LED is durable, high-brightness, waterproof, removable, and acting as a work light. Customers can choose a suitable light source based on their own operation characteristics. Fluorescent can not be used under humid or rainy conditions.
Under Vehicle Search Mirror
ID MD2008B
|
- Applications
This check-mirror is an ideal tool, which is applicable to check cars, machinery, warehouses, schools, factories and others difficult to see directly. It can be used for airport security, parking inspection, the military regional inspection, and personal checks, such as private cars. We have supplied some corresponding products for regional Games, important meetings, local police, top hotels and large-scale factories.
- Statements
- This manual has been revised carefully to pursue the accuracy and perfect content, but it is not guarantee to have no omissions or errors.
- The company preserves rights to modify the hardware and software products not to inform users.
- The company keeps the rights of the final interpretation of the manual.
Mirror size: diameter 30cm
Product Weight: 1. 6kg
Length: 80cm-140 cm
Box Size: 82×22×33cm
|
Package: 10PCs per carton
Carton size: 45×41×89 cm
Gross weight: 30KGS
Offer Rhos and CE
|
| |
|
|
- Introduction
This product is the latest scientific and technological achievements.
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance,
light weight, and high intensity. Product is suitable for police or security services to carry out the hidden-check,
and to operate for a long time. Check-mirror can be stretched, which greatly enhanced the applicability in varieties of environments.
If necessary, the rod can be stretched quickly to have a check, and operator does not bend over.
The product is designed as 180-degree turn around so that it can detect vehicles or goods in detail as possible.
- Applications
This check-mirror is an ideal tool, which is applicable to check cars, machinery,
warehouses, schools, factories and others difficult to see directly.
It can be used for airport security, parking inspection, the military regional inspection,
and personal checks, such as private cars. We have supplied some corresponding products
for regional Games, important meetings, local police, top hotels and large-scale factories.
Under Vehicle Search Mirror
- Package
Product Weight: 1kg
Mirror size: diameter 15 cm
Packing: 20PCs per carton
Carton size: 65×38×44cm
Gross Weight: 20KGS
- Statements
Offer Rhos and CE
|
ID MD2008C
|
| |
The model designed for a long time check the bottom of the vehicle design, table, chair, the underside of vehicles and other necessary objects leaned english: fixed objects such as temporary in english can be used under the U.S. portable ML subsection. MW for the surprise choice of a search operation.
Cabinets, ceilings as well as other necessary climbing search objects can be removed using the MW or the ML
at the end of round to be checked. According to the actual situation in english, if the light situation, coupled with the torch is equipped with supplementary light source on the target object in order to avoid omission english
Packing list:
Can spin the ball
Wanxiang mobile round
Convex, Washers, Flashlight
|
Package: 4PCs/Carton
Packing size: 86×25×32cm
Gross Weight: 8.5kg
|
| ID MD2008D
Specifications:
- Mirror:
- 33 / 28 centimeters high intensity shatterproof acrylic mirror,
- convex-shaped 2-fold amplification effects
- 1/2 weight of the mirror glass which is of the same size
- With certain toughness, not easy to be broken,
- safe, durable, light and glass the same mirror.
- Ebonite materials surround the botton of the mirror, can effectively prevent the collision cause damage to the mirror.
- Detectable minimum height: 10CM
- Grip:
- T-type retractable rod,
- Turning 170 degrees around the joints designed to maximize the depth to the detection of vehicles and goods,
- Two-ball shrapnel,
- Plastic ring double insurance positioning,
- Use of high-quality aluminum structure and multiple high-intensity processing, light , firm, and beautiful.
- Surface dust-free workshop grilled outdoor paint treatment,
- long-term use of non-bleaching, non-smell, harmless to the human body.
- Cotton with a black foam grip, grip feeling good, fit a long time operation.
- Light source:
- Fluorescent lamp, as well as an optional LED light source.
- Fluorescent light source with a natural, soft characteristics; LED lights have long life,
- high brightness waterproof, removable to serve as work lights and so on.
- Customers can use the characteristics according to their own selection of suitable light source.
- Fluorescent models are adapted to wet and rainy conditions
- Power Supply:
- Internal Lithium-electric charge, 1-2 hours for 5-6 hours operation.
- Economic, convenient and practical.
- With the packaging with standard power adapter.
- Carry:
- folded rod, fixed after a good one person can be put away.
- Can be equipped with easy to carry bag, can be dismantled when not in use and collection.
- Materials are in line with the overall process Rhos standards, suitable export to other countries.
|
Vehicle inspection mirror with a DVR function outer zone SD expansion card slot,
when working, you can also record the whole working process, can also record the
file through the USB interface on the device to save the file to a computer or other
storage media to facilitate a long time to save data.
In addition, the device's display do not only has the general features of the liquid crystal display,
but also a multi-function multimedia player. In your spare time, you can play multimedia files and browse e-albums and book. details please following the use of product operation
|
| DVR vehicle inspection mirror
ID MD2008E
Introduction LCD / DVR
- Function keys
- Basic function and the introduction of Icon
To allow users to quickly master the use of the product,
the product instructions, only highlights the surveillance video recording and video playback capabilities,
other functions, depending on introduction to learning the use of function keys
- A music player: Support MP3/WMA/AMR/ACC/FLAC/AP
- Video display: Support RM/RMVB/3GP/MP4/FLV/AVI/ASF
- Picture browsing Support JPEG format pictures, Full screen display, thumbnail display, slide show.
- E-book: You can read TXT text.
- Audio: microphone recording.
- Shooting
- Video output
- Surveillance video: This function will explain the details on the operating instructions.
- Games and calendar functions
- System Setup Function
- Function with a SD expansion slot
Package: 3PCs per carton
Carton size: 86 × 35 × 28 cm
Gross Weight: 18KG
|
|
| Specification
- CAMERA£º
Resolution: 1 / 3 inch
Chip: 420 line Sharp CCD
Power Supply: DC12V
Automatic infrared night vision function
- LCD/DVR
Screen size: 4 inches
Resolution: 480 × 320 × RGB
Power supply: Built-in 3.7V rechargeable battery
PACKAGE LIST
One Camera
One Host Box£¨with Aluminum£©
One DVR /LCD
Two Charger £¨13.8V/1000mA¡¢5V/1A£©
BATTERY
- HOST BOX CHARGE
When the screen images distorted or no images and the indicator behind the host box is not extinguished,
you should charge the host box. Using the 13.8V/1000mA charger to change the Host Box, at the process,
at first it is red, when full, it is green
- LCD/DVR CHARGE
When appears the low-voltage logo on the screen or automatic shutdown,
you need to use the 5V/1A of small charger to charge the DVR.
Charging time is normally 4-8 hours, preferably not more than 8 hours,
or DVR's Built-in battery life will be affected. In the process of charging,
DVR the will be a small indicator light is red on the lower right corner of DVR ,
green when it is full.
| |
|
|
|
Visual inspection under the vehicle mirror
Simple operation, press the boot button can be used to examine the car, machine, warehouse,
schools, factories, equipment, or other areas to watch the ideal directly,
it can be used to check mirrors airport security, parking area military private individuals, etc.
Product features
The display USES color pigment 265 million TFT LCD digital. Exclusive exploitation has driven plate,
about five times the image and strong function of electronic variable light etc.
Make your picture more bright colored color more lifelike. SONY, a CCD camera using sensor,
10~16 feet, make you even in infrared night also apply to normal.
Using aircraft type triangular wheels, operation, use lighter more comfortable.
Specifications
Voltage: DC12V
Current: 220mA
3.5inch TFT LCD digital
Resolution: 320 × 240
Analytic: 420 line level
Power supply:
rechargeable lithium
battery protection
SONY CCD camera:
the sensor
Wide-angle lens perspective: 120 °
Infrared distance: 10~16 feet
|
Package: 3PCs/Carton
Packing size: 86×35×27cm
Gross Weight: 23kg
|
|
|
| ID MD2008G
embed the triangle turn-plate into the red nylon ball.
|
|
|
| pull the thin aluminum pipe out of the thick one, then circumvolve the thin one to lock the whole telescopic pole.
|
|
|
| Please connect the mirror and the pole by inserting the thin pole into the joint on the mirror.
|
|
|
| As shown in Pic6, fix the spare electric torch on the telescopic pole and finish the installation.
|
|
|
|
Operation
Bottom Explanation of inspection Mirror
- For more convenient to use, please install the triangle turn-plate first when use the inspection mirror.
And the turn-plate can be turned 360°
- You may turn on the spare electric torch either on the top or on the bottom to get a better view when the light is not bright enough.
- If the telescopic pole is not long enough, you may choose any of the four additional lengthen poles, and every one of them has handgrip.
Top Explanation of inspection Mirror
- You don't need to install the triangle turn-plate. And you can adjust the angle of inspection mirror by the revolving button accommodated.
- You may turn on the spare electric torch either on the top or on the bottom to get a better view when the light is not bright enough.
- If the telescopic pole is not long enough, you may choose any of the four additional lengthen poles,
but every one of them has handgrip.
|
|
Model: MD2008H
Intelligent Under vehicle inspection System
Product Introduction£º
MD2008H type under vehicle inspection equipment is a multifunction security new product.
It can show clear images of 4 directions in the same time and expanding our field of vision.
There are two modes at security check: mobile mode & fixed mode.
For checking banned substance on the bottom of vehicle.
It can be also installed in allow vehicles of all kinds of places of inward and outward or access to be seized vehicles, the bottom acquisition vehicle image to determine whether the bottom with bombs, drugs to prohibited item.
This product has the DVR function, very convenient to save the images to SD card to do backup work, let security personnel fast inspection, improve the work efficiency.
The product is suitable for use in the airport, seaport, customs, prison, the military restricted zones and the hotel security for automobile chassis for inspection area. Below is the function of the product introduction and instructions for use. please read carefully, wish you enjoy using it.
Function Introduction£º
- 15inch-LCD panel Introduction
| Display panel
| 15 inch color LCD panel
| Resolution
| 1280x1024
Support multinational language menu
| SD card digital recording
| Recording format
| AVI
| Storage medium
| SD card
| Power
| DC
| 12V
| | | | | |
Installation
- Connecting rod-1
- Connecting rod-2
- U-Iron clip
- leading wire
- camera head-1
- camera head-2
- camera head-3
- camera head-4
- LED light filling
- Bottom plate
- wire connecting head
- Pick up the connecting rod-2, the bottom plate and the screws. Fixed the connecting road-2 on the U-clip of bottom plate, tighten the screw.
- Connect the leading wire to the bottom plate.
- Connect the connecting rod-2 to the connecting rod-1
- fix the leading wire with the Velcro straps
- Finish installation
Camera head
- The instrument has four hd SONY camera , We can watch the pictures from different directions
- This equipment with the filling light source, 12v LED high brightness lights supplement, it will be more clear while in insufficiency light, and fill-in light for the camera. light fitting luminance is accommodation.
|
|
-
Digital recording box
- Control switch
- Camera brightness adjustment
- Video output socket
- Battery power indication
- DVR-up Choose
- DVR-left choose
- DVR-Menu choose
- DVR-down choose
- DVR-right choose
- Camera head connecting
- DVR-Recording/stop/play
- DVR-file display
- DVR-video stop
- DVR-playback
- Charge socket
- Double track headset socket
- SD card socket
- Microphone plug
- Fuse socket
- 4 screens interface
|
|
- Digital recording button operation
| ¡ü
| Menu up choose
|
|
| ¡ý
| Menu Down Choose
| ←
| Menu Left choose
| →
| Menu Right choose
| OK/Menu
| OK/Menu
| Power
| Power indication
| Status
| Working status
| Playback
| Video playback
| Stop
| Stop play
| Preview
| Video preview
| Rec.
| Manual recording & stop
| | | | | | | | | |
- Icon instruction
| SD insert
|
|
Manual video mode
Manual shoot mode
Auto checking mode
Moving checking mode
Date 2010/03/31
| Time 16:29:45
| | | | | |
Data/time setting
- Before using, insert the SD into the VCR. Press 'ok/menu' to the Menu screen, and press '→'to clock icon.
- Choose the 'Set time/Date' and press 'ok' to enter the time/date setting. press 'left' or 'right' icon to choose the setting item. 'up' & 'down' is adjusting the time. after setting , press ok and return back to last menu.
- User can set the data format according to your habit. For example£º YY/MM/DD or DD/MM/YY. ( YY:year MM:month DD:date )
- Master Capture
- press 'ok' enter the menu, choose the
icon. And press 'Master Capture' enter the setting.
- There are 4 chooses, function as following
Photo 1: Master Capture, every operation for shoot 1 picture
Photo 3: Master Capture, every operation for shoot 3 pictures
Movie: Master Capture, every operation for start record & REC file
Movie Clip: Manual recording, every operation for start record and the file is 10sec/chapter
- Auto Capture recording setting
- Press 'OK' enter into the Menu, choose the icon. and enter to the 'Auto capture' setting.
Auto Capture: press ok, choose 'on' for start on the Auto capture. choose 'off' to shut up Auto capture.
- Mater Capture: in this mode, there are 4 working status:
Photo 1£ºAuto Capture, every operation for shoot 1 picture
Photo 3: Auto Capture, every operation for shoot 3 picture
Movie 5s: Auto Capture, every operation for start record and the file is 5sec/chapter
Movie 10s: Auto Capture, every operation for start record and the file is 10sec/chapter
- Movie Pre Record£º
Press 'on' is start-up, 'off' is shut down the function of Movie Prerecord.
This function can help to record the two parts of the documents, the first paragraph for the second video recording interval before 2-3 seconds sound.
- File Over Write Setting
Press 'on' is start-up, 'off' is shut down the function of File Over Write .
After starting this function, when the memory space is less than 10 MB, the system will auto-delete the forehand 100MB file for saving new file.
- Motion detect range & sensitivity setting
Press OK to enter the Menu. Choose the
icon, enter the motion detect range & sensitivity setting.
Range,Motion detect range£ºpress direction choose 1/1 (full screen),1/4screen, 1/16 screen is control area.
Timeslot, Time interval: motion detecting scanning time interval. Can choose: 1 Sec/time, 3sec/time, 5sec/time.
Sensitivity, Motion detect sensitive£ºAccording to the direction key choose the sensitivity of Low, Middle or High. The higher the sensitivity, motion detecting triggering possibility is higher.
- Photos quality & standard setting£º
- Press OK enter the menu, choose
icon. Enter the photos quality & standard setting.
- Photo Quality, (Please see below form of resolution details)
- High quality
- Standard quality
- Low quality
- Movie Quality,(Please see below form of resolution details)
QVGA,QVGA---Image resolution
Resolution parameters
| States
| Video
| Image
| CHI
| CHI
| D1&HIGH
| 720×576
| 720×576
| D1&Standard
| 720×576
| 720×576
| D1&Low
| 720×576
| 720×576
| QVGA&HIGH
| 360×288
| 720×576
| QVGA& Standard
| 360×288
| 720×576
| QVGA& Low
| 360×288
| 720×576
| | | | | | | |
- TV Output Standard, TV output format choose according to different countries TV format, UP & down key to choice the PAL or NTSC system, click OK to determine and exit
- Video playback
In standard mode, press the 'playback' enter the video playback mode. according to the date showing, press the "←""→"key to play the needed video. and press "Rec." can restart.
- DVR file more frames preview£º
Video playback mode, press the 'Preview' key, we can see preview the 6 photos. and according to the data showing, press "←""→"key to move the yellow selection box. choose the needed video and click 'OK', then play video.
- DVR file deleting£º
In standard mode, press "Playback" to enter the video play mode, click the file you need to delete, and click the ok .At this time, according to the key tips 'File delete' to choose the operation, press the "OK" button execution.
Format:
format all the files in SD card (this operation executed, SD card will be lost in all the documents, can't restore)
- Computer access to files
Insert the SD card to computer, click "my computer" choose "moving disk". And enter the file which named "CCTV".
Enter this folder, and we see some folders inside.. These folders are named by the date of the generation.
Sample£º10032600. The format is: year, month, date,
Enter the folder; we can see some videos or photos. These videos or photos are named by the time of the generation.
Sample:133105-1.. The format is: hour, minute, second
Users can use the ordinary player to play the video. For images files it's jpg format.
- 15inch display panel characteristics
| fps
| Pal:25f/sec, NTSC:30f/sec
| Resolution
| D1:720X576
QVGA:360X288
| Compressed format
| M-JEPG & Standard JPEG
| Detecting mode
| Auto capture
| Working mode
| Recorder/shoot
| Memory
| SD/SDHC¿¨,≤32GB
| Power
| DC12V (5V-36V customized )
| Working current
| ≤250Ma
| Working temperature
| -10°C~+50°C
| Working humidity
| 20%~85%
| | | | | | | | | | |
- 4-ways of color video processor
- system characteristics£º
(1) Link 1-8 camera video signal, adjustable brightness, contrast and saturation, color and sharpness
(2) high definition
(3) NTSC standard£º720x480¡¢60hz,PAL format£º720x576¡¢50hz
(4) The diversity of the display mode, four frames, the two images, single picture, the paint of paint to be automatic switch display mode
(5) High performance screen freezes function: flashing pictures capture
(6) high-performance graphics electronic amplification function, can choose magnified area
(7) Diverse characters cascade information, a camera in the title, headlines and real-time and alarm date/video lost/motion detecting information.¡£
(8) menu language support in both Chinese and English, can be in four exchange pictures and single picture mode playback¡£
(9) provide several input methodes£º(if need for external alarm output function, need another request to add this function)Alarm input, video lost detects, motion detecting can record article 60 incident reports, built-in buzzer alarm¡£
- Panel key function
Definition: short press buttons don't more than 1 second, long press please more than 1 second¡£
- MENU: long press into the main MENU, exit key, short for enter A or page
- AUTO: long press into single picture switch, short for screen freezes in.
- ZOOM : long press enter magnifier function, first short press for image-2, the second short press for image 1, the third short press for two images, the fourth press is 8 picture.
- VCR: long press into the picture, short press for playback by entering/exit channel model, in the menu key change under the mode of menu for ok button.
- 1/5 key : for the camera first channel and the fifth channel, up & left control function
- 2/6 key : for the second and sixth channel camera channel, up & right control function
- 3/7 key : for the third and seventh channel camera channel, menu mode left key for menu mode for moves left reduce function
- 4/8 key : for the fourth channel and channel 8 camera, menu mode right shift to increase function
- Menu
Step£ºUnder any mode , we long press the MENU button, can enter to the main MENU.
(1) Menu setting method£ºlong press MENU enter the main menu click "¡÷¨Œ"key to chanage the cursor choose the menu item.,press ENTERkey to confirm,click"¡÷¨Œ"for left & right moving,and click""forincrease the reduced parameter
(2) System setting
In MENU mode we click "¡÷¨Œ"to choose the ¡®system setting¡¯ and press ¡®ENTER¡¯ to enter
Setting Option.
×1for data: Year, month, day setting£»
×2for time, Hour, minute, second setting
×3 for NTSC¡¢PAL setting£»
×4 for menu language Chinese / English exchange£»
×5 for factory re-set£ºmove the cursor to ¡®OK¡¯ press "ENTER"and choose "YES" press "ENTER" to confirm,after reset safety it auto return to menu. After long press ¡®MENU¡¯ reset finish.
- Display setting
Press "¡÷¨Œ"to move the course to "dispay setting" and click ¡®ENTER"into display setting
×1 For the camera title switch
×2. For the date switch
×3 For the time switch
×4 For the line coordinate position setting .
×5 For the line coordinate color and the line coordinate switch
- Repeat setting
Under the main menu model
"¡÷¨Œ" key cursor selected "repeat setting" then press "ENTER" key into setting options.
OFF show automatically switch to turn off. automatically switch to time 00-99 seconds then can be changed, ( 4 line splitter default all single screen.)
Automatically switch to turn on,8 line splitter default all single screen will automatically switch to turn off
- Channel setting
When use "¡÷¨Œ" key selected " channel setting" key then press "ENTER" key into setting options
×1 show the title setting mode, press ""key will appear Character box,
According to the change in the box title character
×2 show adjustable brightness, contrast, color, saturation, sharpness
×3 For image setting mode, when setting selected "ON" press
The camera signal will such as a mirror display opposite direction .then the default setting is "off" press "MENU" key to exit.
- Remove setting
Under the main menu mode with "¡÷¨Œ" key select the "Remove Settings" and then press "ENTER" to ENTER setting options
×1, Surveillance time switch Settings, when set choose "ALWAYSON" it will be effect.
×2,Surveillance's sensitivity
×3,Surveillance's area coordinates
- Event setting
Under the main menu mode with "¡÷¨Œ" key select the "Event Settings" and then press "ENTER" to ENTER setting options
×1,external alarm, video lost, motion Surveillance switch Settings.
×2,The delay time of the buzzer alarm
×3,Time to record the delay time.
×4,The discretion of the potential buzzer alarm Settings
- Event report
Under the main menu mode with "¡÷¨Œ" key select the "Event report " and then press "ENTER" to ENTER setting options
1,NO¡¢DD-MM-YY¡¢HH£ºMM£ºSS¡¢CH¡¢EVENT they are showed the number of alarm , date, time, the channel and the type of event.
2, LISTCLEAR For all the records are empty
Note: Take NO set to YES then press ENTER key confirm completely empty. This report total 6 pages, it can record 60 pcs incident reports.
- Four ways color video processor parameters
- Note
(1) Please read the manual carefully before using this system.
(2)Avoid using the device in extremely cold, heat, moist area, it may damage the device.
(3)Please back up the SD card always, and do not forced pull off the SD card when it is on working, because it easy to damage the instrument and the SD card.
(4)Please make sure all accessories connected, and then open the power, and the monitor and DVR will set up after 5 seconds of power on.
(5)Please adjusts light complement such as LED, so that let the image showed as the best effect. Adjustment the brightness, color and contrast to let the display is best.
(6)If you want to view with big screen, please let video output connected to input of large screen display.
(7)Please install fuse (F3A250V) before using it.
(8)after used the machine, please clean up the equipment, wipe off the residue.
- After-sales Service
This product can be replacement within one month from the date of purchase.
if it is belong the products itself problem, we can supply one year warranty period after our company confirmed.
And for improper operation we can provide free repair, but need the purchase paid the repaired material cost.
Please include you original purchase data.
This warranty does not apply to accident, improper use, improper maintenance, disassemble the equipment and the failure caused by misuse of equipment, this is also not suitable for non-authorized personnel have done any maintenance equipment.
- Legal Liability
(1) Law interpretation
The manual interpretation and reproduction rights belong to the Company.
(2) Trademark Right
The vehicle inspection mirror instrument¡¯s model name, logo belong to our company right. Please do not copy it.
(3) Tortious Liability
Without the Company's permission to reproduce or use the equipment and equipment of our company name, logo, belong to the infringement, should bear all the resulting of legal liability.
- Packing list
- 15 inch display
- color video processor
- the connecting rod (2pcs)
- the signal lines
- charger,
- digital video recording box
- bottom camera device,
- product specification
- adjustable wrench
- Technical parameters
- Camera: Sony, pixel CS (dpi);
the type of model: G639 + S3172 +2096;
Type: CCD main board; image sensor: 1/3-SONY COLOR ;
level resolution: 480 (TVL, Minimum illumination 0.1 (Lux), resolution of 480TV Lens CS (mm), SNR> 48 (db), back light compensation :AUTO; Size: 1 / 3 (inch)
- Operating voltage: DC12V (rechargeable)
- Rod Length: 1.3 m
- Camera base device height: 9.5cm
- Operating temperature: -10 °C - +50 °C (°C)
- Net weight: 8.6Kg
- GW: 15.1Kg
- size:
Display: 46.6 × 19 × 38.5cm
Body packing: 74 × 42 × 7cm (Aluminum Packaging)
|
|
| Compact Pocket Search Mirror and Torch MD2008I
Pocket Under Vehicle Search security Mirror with carry case
Pocket Search Mirrors provide a quick and effective visual search capability for law enforcement
officers and for individuals with personal security concerns.
In addiction, specialized task units often require a similar capability optimized for tactical use.
A compact search mirror that can be carried as an aid to personal security or as an individual issue by operational personnel.
Fitted with a convex glass mirror, telescopic arm and a miniature flashlight. The PMT folds flat for carrying in a jacket/uniform pocket or bag and weighs only 260g(9.2oz)
The pocket mirror can be adjusted for angle and provides a wide field of view.
The unique telescopic handle extends to 460mm(18.1in) and is completely rigid to ensure a stable image.
The integral flashlight can be used with the mirror open or closed.
A tactical version of the pocket search mirror fitted with an acrylic mirror.
|
|
The PMT can be used in operational scenarios (e.g. police SWAT) where unobtrusive close in observation is required by individual officers. During IEDD tasks the
PMT allows a quick confirmatory visual check to be made before positive action is taken against a suspected hazardous device.
The small, lightweight and similar situations where other visual search mirrors would be too large or widely.
Supplied with 2x AAA batteries and a spare lamp in a stowage compartment.
Overall dimensions closed (both versions): 155×90×20mm ( 6.1×3.54×0.079inch ) Weight: 250g ( with battery )
|
|
|
|
|
|
|
Components
- Telescopic set
- Torch cap
- Mirror
- Torch body
- Spare bulb
- Bulb
|
HOW TO USE
- The telescopic set was combined by 8 sections aluminum rods which could be extend or fold easily without tools.
- The users could adjust to a idea length for more convenient searching work.
Caution
- Please do not over extend the rods set by force. It may cause the nylon junction parts break.
Battery or Bulb Replacement
- Simply unfold to suitable viewing angle. The torch operates by the Push button. The handle may be extended by pulling outward from the Centre finger recess, located next to the torch on/of button.
The torch May also be used with the mirror folded flat.
To remove the torch batteries and bulb, grip the top cap and unscrew Anti-clockwise. This will be found easier with the handle sections extended.
Caution
- Batteries and bulb will new drop out when the torch is up ended. A spare bulb is supplied, located in the torch lamp head, removing the rubber grommet will allow access.
Maintenance : Install batteries correctly, observing the polarity + - signs to avoid leakage. Always replace sets of batteries at the same time, taking care not to mix old and new batteries from equipment.
Batteries replacement batteries : 2xMN 2400 or similar. Size AAA1.5.
|
|
|
MD2008J
Introduction
This product is the latest scientific and technological achievements.
The rod is made of Aluminum alloy, which has some characteristic such as Silver white appearance, light weight, and high intensity.
Product is suitable for police or security services to carry out the hidden-check, and to operate for a long time.
Check-mirror can be stretched, which greatly enhanced the applicability in varieties of environments.
If necessary, the rod can be stretched quickly to have a check, and operator does not bend over.
The mirror is made of non-friable acrylic instead of ordinary glass plated mercury.
The mirror tray is made of the special materials, which are not easy to aging and broken, and very durable.
Products are equipped with adjustable hand-held rod.
The range of rod length is from 46cm to 88cm.
The unique folding design brings about space-saving and portability.
The product is portable when its rod is folded on the check-mirror. One person can take it.
When not in use, the product can be disassembled and collected in the portable bag.
(There are two kinds of packages: Aluminum box and carton for your choice)
Operation guide
Rod: Extendible T-bar, fixed by spring with two beads, which are made of high-quality metal and many high-strength processing, is light weight, strong and beautiful. The surface of rod is dealt with baked-paint in the dust-free workshop. The painting does not fade after long-term use, and is odor-free and not harmful to humans. The rod is equipped with black foam handle which has a good holding sense and can be operated comfortable for a long time.
Power: Built-in lithium battery. To charge 1-2 hours supply for 5-6 hours of operation. It is economical, convenient and practical.
Mirror: A 30 cm ¡Á 30 cm high-intensity shatterproof acrylic mirror is made of non-friable acrylic instead of ordinary glass plated mercury. The mirror tray is made of the special material which is not easy to aging and broken, and very durable.
Operation steps
First, open the aluminum packaging, take out the check-mirror; then stretch the rod to carry out operations.
If it is not need, put the rod away into the box
when the battery runs out and needs to charge (with a standard power adapter in the package),
it is necessary to turn ON. When the green light of power adapter is OFF, it indicates that the battery has been fully charged.
|
In a dark place, you can turn on the lamp switch
|
Other parameters
Product Weight: 2.5kg
Total weight: 4.6kg
Length: 50cm-100cm
Packaging: 50cm¡Á35cm¡Á18cm
Statements
- This manual has been revised carefully to pursue the accuracy and perfect content, but it is not guarantee to have no omissions or errors.
- The company preserves rights to modify the hardware and software products not to inform users.
- The company keeps the rights of the final interpretation of the manual.
The materials are in line with Rosh technology standards
| |
Package: 1PC per carton
- Aluminum trunk 48cm × 39cm × 19.5cm
material: fire protection
- Carton size: 50 × 40 × 20cm
- Gross weight: 10KG
|
Pipe Inspection Camera
Special feature: Waterproof / Weatherproof
- pipe inspection equipment
- pipe & wall inspection system
- sewer services inspection
Specification
Camera
| camera size:
| 23mm×120mm Front size:45mm
| Camera case material:
| stainless steel house stainless steel 304
| Camera glass material:
| saphir glass
| sensor size:
| 1/4 inch
| Total Pixels:
| PAL:720×576 NTSC: 720×480
| view angle:
| 120°
| camera light:
| 12PCS white LEDS
Special gold point touch connector
| waterproof:
| IP68
| camerawork current:
| 100MA
| camera power supply:
| DC 12V
LEDS ADJUASTABLE
| Work temperature:
| -10°C-50°C
| | | | | | | | | | | | |
Monitor
| monitor size:
| 7inch TFT color monitor
| monitor Total Pixels:
| 1440×234
| monitor power supply:
| DC 12V
| display language:
| English
up,down left,right adjustable
| Model
| 16:9 4:3
sunshade include
waterproof connector
| Work temperature:
| -10°C-50°C
| | | | | | | | |
DVR
| DVR power supply:
| 12V
| DVR work current:
| 200MA
| storage medium:
| SD card (max 32G)
digital clock and digital calendar
| DVR Total Pixels:
| 720×576 (D1)
picture snap and movie record
| movie format:
| AVI
audio record (yes)
| double earphone output
| | | | | | | | |
Audio input unit
- microphone
- clip type
Cable wheel
- Cable size:320MM(diameter)×110(h)
- Wire material: fiberglass rod
- Fiberglass length:20M( standard)
- Fiberglass diameter:4.8MM
- Fiberglass color:yellow
Battery
| Battery type:
| 12V 4000MAH rechargeable
Li-ion battery(18650)
| Work time:
| 7 hours
| |
Charger
- Input: AC90-260V
- Output: DC 12V 1000MA
- Output cable length:1.5M
- DC plug diameter :2.1MM
SKIDS size
- SKIDS1: ¦µ40MM
- SKIDS2: ¦µ80MM
|
|
|
